Biotronix Solution Forever® presents the TDCS TPCS TACS TVNS Integrated Neural Stimulation Machine, an advanced multi-modal neurostimulation platform designed for professional neurotherapy, neurorehabilitation, neurological rehabilitation, physiotherapy, and clinical research environments. The system integrates four stimulation modalities—tDCS, tPCS, tACS, and tVNS—into one professional platform, providing a versatile solution for different non-invasive neuromodulation and electrical stimulation applications.

The Integrated Neural Stimulation Machine combines multiple stimulation technologies in a single compact and portable setup, allowing professionals to select different stimulation modalities according to their clinical or research protocols. With adjustable treatment parameters, multiple waveform and treatment modes, rechargeable battery operation, a color TFT display, and dedicated stimulation accessories, the system is designed for convenient and flexible professional use.

Built with medical-grade components and precision control electronics, the tACS stimulator allows accurate adjustment of stimulation frequency, current intensity, waveform parameters, and session duration. The compact and portable design makes it suitable for use in hospitals, clinics, rehabilitation centers, and research laboratories. Integrated safety features such as current limiting, impedance monitoring, electrode contact detection, and automatic shut-off ensure safe and stable operation during repeated sessions. The system is compatible with standard electrode pads and adjustable headgear to maintain consistent electrode placement and reliable neuromodulation protocols.

Key Features

• Advanced integrated neural stimulation technology
• Integrated tDCS, tPCS, tACS, and tVNS
• 4-mode professional neurostimulation platform
• Multi-modal neuromodulation technology
• Non-invasive electrical stimulation approach
• Compact and portable professional design
• 2-inch Color TFT Display
• USB Type-C charging port
• Up to 8 hours of continuous output
• Treatment duration from 5 minutes to 4 hours
• Adjustable stimulation parameters
• Multiple waveform and treatment modes
• Rechargeable battery operation
• Convenient professional operation
• Suitable for neurotherapy and neurorehabilitation
• Designed for clinical and research environments

Technical Specifications

General

• Main Unit Size & Weight: 88 × 55 × 15 mm, 140 g
• Display: 2-inch Color TFT Display
• Battery Charging Time: 2.5 Hours
• Charging Port: USB Type-C
• Battery Working Time: 8 Hours of Continuous Output
• Treatment Duration: 5 Minutes – 4 Hours

tDCS – Transcranial Direct Current Stimulation

• DC Current: 0 – 4.5 mA
• Waveform Modes: DC, Pulse
• Maximum Voltage Limit: 28 V

tPCS – Transcranial Pulsed Current Stimulation

• Stimulation Type: Transcranial Pulsed Current Stimulation
• Waveform: Pulsed Current
• Treatment Mode: According to selected protocol
• Application: Professional Neurostimulation & Rehabilitation

tACS – Transcranial Alternating Current Stimulation

• AC Current: 0 – 4.5 mA Peak
• Frequency Range: 0.2 Hz – 80 Hz
• Waveform: Sine Wave

tVNS – Transcutaneous Vagus Nerve Stimulation

• Frequency Range: 1 Hz – 1000 Hz
• Pulse Width Range: 50 µs – 500 µs
• Waveform Modes: Biphasic, Alternating
• Treatment Modes: Continuous, Intermittent

Additional TVNS Treatment Parameters

• TVNS Frequency: 25 Hz
• Pulse Width: 200 µs
• Treatment Mode: Continuous
• Waveform: Biphasic
• Treatment Duration: 20 Minutes
• Recommended Treatment Dose: 20 Minutes per Day for 2 Weeks

Accessories

• Sponge Electrode: 65 mm
• Headgear: Headband/Cap, M Size
• Lead Wire: 2.0 mm Pin, 1.5 m Length
• Ear Clip: Dual-Side Electrode
• Wire Fixing Clip: Black
• USB Cable: For Charging and Data Transfer

Applications

• Neurological Rehabilitation
• Neurorehabilitation
• Professional Neurotherapy
• Non-Invasive Neuromodulation
• Brain Stimulation Research
• Motor Rehabilitation Research
• Cognitive Rehabilitation Research
• Physiotherapy & Rehabilitation
• Clinical Neurostimulation
• Neurological Therapy Programs
• Professional Rehabilitation Centers
• Neurostimulation Research
• Clinical Research Environments
• Professional Neuromodulation Applications

Benefits

• Combines tDCS, tPCS, tACS, and tVNS in one integrated machine
• Provides a versatile multi-modal neural stimulation platform
• Supports multiple non-invasive neurostimulation approaches
• Offers flexibility for different professional stimulation protocols
• Reduces the need for separate devices for different stimulation modalities
• Provides convenient access to multiple neurostimulation technologies
• Compact and portable design supports easy handling and transportation
• Rechargeable battery enables convenient professional operation
• Color TFT display provides convenient monitoring of device settings
• Up to 8 hours of continuous output supports extended operating sessions
• Adjustable treatment parameters provide protocol flexibility
• Suitable for professional neurotherapy and neurorehabilitation environments
• Supports clinical and research-based neurostimulation applications

Highlights

• Integrated Neural Stimulation Technology
• 4-Mode Neurostimulation
• tDCS – Transcranial Direct Current Stimulation
• tPCS – Transcranial Pulsed Current Stimulation
• tACS – Transcranial Alternating Current Stimulation
• tVNS – Transcutaneous Vagus Nerve Stimulation
• Multi-Modal Neuromodulation
• Non-Invasive Brain Stimulation
• 2-Inch Color TFT Display
• USB Type-C Charging
• Up to 8 Hours Continuous Output
• Portable Professional Design
• Rechargeable Battery
• Adjustable Treatment Parameters
• Neurorehabilitation Applications
• Clinical & Research Use

Why Choose This Integrated Neural Stimulation Machine?

The TDCS TPCS TACS TVNS Integrated Neural Stimulation Machine brings four different stimulation modalities together in one professional platform, providing greater flexibility for facilities working with multiple neuromodulation technologies. The integration of Transcranial Direct Current Stimulation (tDCS), Transcranial Pulsed Current Stimulation (tPCS), Transcranial Alternating Current Stimulation (tACS), and Transcutaneous Vagus Nerve Stimulation (tVNS) provides a comprehensive multi-modal setup for professional neurotherapy, neurorehabilitation, and clinical research environments.

Its compact design, rechargeable battery, color TFT display, and adjustable treatment parameters make it convenient for professional operation. The system can be incorporated into neurorehabilitation centers, neurotherapy clinics, physiotherapy facilities, neurological rehabilitation centers, and clinical research environments where non-invasive neurostimulation technologies are included in professional rehabilitation or research protocols.

Integrated 4-Mode Neural Stimulation Machine for Professional Neurotherapy & Neurorehabilitation
